ADVIA 2120i Haematology System


advia_2120i_flyer.pdf


The ADVIA® 2120i Haematology System has been withdrawn from the market by Siemens Healthineers with a replacement to be launched in due course. In the meantime, please consider the InSight V5R Veterinary Haematology Analyser.

The ADVIA® 2120i Haematology System is the only haematology system for human and animal samples offering complete multispecies haematology testing capability with practical automation.

Features

  • High throughput capacity of 120 samples per hour with sophisticated technologies for analysing White Blood Cell (WBC) Differentials, Red Blood Cells (RBC) Reticulocytes and Platelets
  • Accepts up to 150 samples at a time
  • 21 pre-programmed species provide ready-to-use cell gating across a wide spectrum of species and an unlimited number of user-definable archetypes allow easy expansion to new species
  • Unique playback function allows replay of sample results in alternate species without redrawing or retesting
  • Data manager provides full traceability at no additional cost so you can run customised reports at any time
  • Autoslide connectivity
  • NRBCs on every sample
  • Body Fluid Capability
  • Unique UnifluidicsTM Technology
  • Efficient and cost effective workflow
  • Fully automated daily maintenance
  • 'Right first time' results

Specifications

Parameters

CBC Results
WBC, RBC, Hb*, HCT, MCV, MCH, MCHC, CHCM, RDW, HDW, CH, CHDW, PLT
Differential Results (Absolute and %)
NEUT, LYMPH, MONO, EOS, BASO, LUC (Large Unstained Cells), NRBC
Platelet Results
PLT, MPC, PDW, PCT
Reticulocyte Results (Absolute and %)
RETIC, MCVr, MCVg, CHCMg, CHCMr, RDWr†, HDWr†, CHg, CHr, CHDWr†
CSF Assay Results
RBC, WBC, Absolute and % NEUT, LYMPH, MONO, EOS†, BASO, PMN, MN
*CN-free Hb method      †For research use only


Sample Modes/Volumes

Automatic Closed Tube
175µl
Manual Closed Tube
175µl
Manual Open Tube
175µl


Test Selectivity/Throughput

CBC
120 samples/hour
CBC/RETIC
74 samples/hour
CBC/DIFF
120 samples/hour
RETIC
74 samples/hour
CBC/DIFF/RETIC
74 samples/hour


Weight & Dimensions

Analytical Module with Autosampler:
Weight
193kg
Height
86cm
Width
141cm
Depth
68cm


Analytical Module without Autosampler:
Weight
163kg
Height
86cm
Width
81cm
Depth
68cm


If you would like more information please contact Woodley Equipment on +44 (0) 1204 669033 or email sales@woodleyequipment.com
