CellaVision DC-1 Digital Cell Morphology System


cellavision_dc_1_flyer.pdf


The CellaVision® DC-1 is designed to automate and simplify the process of performing blood cell differentials in low-volume laboratories.

The system leverages high-speed robotics and digital imaging to automatically locate and capture high-quality images of cells.

Features

  • Capture digital images of cells from blood smears
  • Automate the analysis of WBCs, RBCs and PLTs
  • Create digital scans of any interesting specimen
  • Compact design with small footprint

Specifications

Slide Handling

  • Accepts slides with ground edges, clipped, round or square corners
  • Order ID for slides entered either manually or using an optional barcode reader
  • Slides are loaded one at a time
  • Analyses slides with blood smears
Immersion Oil

  • Manual oil dispensing
Quality Control

  • Cell location accuracy test for the verification of hardware and stain quality
  • Built-in smear check
Archiving of Results & Images

  • Utilising LAN
Storage Capacity

  • Primary Storage: On local hard drive up to 1500 slides (20GB)
  • Secondary Storage: Unlimited when transferred to external storage media
Printer Support

  • Laser/inkjet printers supported by Windows
Communications
  • Bi-directional LIS support, ASTM
  • Ethernet 10/100 Mbps
  • Multiple CellaVision DM/DC analysers can share a database
System Components

  • Slide Scanning Unit with integrated PC and Windows 10 embedded
  • CellaVision DM Software
Electronical Specifications

Analyser:

  • Voltage input 12 VDC
  • Current input 7 ADC
Power Supply:

  • Voltage input, power supply 100-240V
  • Voltage frequency, power supply 50-60 Hz
  • Current input 1.2-0.6 A
Dimensions/Weight

  • Width - 280mm
  • Depth - 390mm
  • Height - 370mm
  • Weight - 11 kg
Throughput*
*NOTE: Processing time may vary depending on smear quality, WBC concentration & number of non-WBC's
  • Up to 10 slides/hour for complete differential (100 WBC+RBC+PLT)
Slide Preparation Methods (Wedged)

  • Automated slide makers and stainers
  • CellaVision® SmearMaker
  • HemaPrep®/MiniPrep® automated blood smearing device
  • Manual smears
Stains
  • Romanowsky stains (May Grünwald Giemsa, Wright Giemsa, Wright)
Optional Software/Applications

  • CellaVision® Remote Review Software
  • CellaVision® Server Software
  • CellaVision® Proficiency Software
  • CellaVision® Dashboard
