The epoc® provides accurate and immediate blood gas/electrolyte and critical care biochemistry results directly to a handheld PDA (included) and wirelessly interfaces to an electronic data manager (EDM) and Bluetooth printer.
Features
- Accurate blood gas, electrolyte and critical care biochemistry results in 3 minutes
- Room temperature card storage
- 92µl sample, fresh whole blood (arterial, venous or capillary)
- Completely portable with rechargeable battery and Bluetooth printer
- Ready to use anytime, anywhere - in-practice, theatre, patient side or equine yard
- Easy to use with touch screen technology
- Wi-Fi and Bluetooth enabled - easy transfer of data and automated software updates
- EDM Lite software and large data storage
- Automatic self calibration and quality checks
- Low cost analyser and cartridges
- Single-use, self-calibrated test with barcoded SmartCard™ technology for improved safety and total quality assurance
- Ability to input all patient data, species, temperature and ventilator settings - analyser stores 2000 patient results
NEW epoc NXS Host
- Automated software updates through Wi-Fi
- Simple, intuitive user interface, similar to that of a smartphone
- Touch screen navigation including 'Show me how' videos
- Colour coded results for easy interpretation
Suggested Applications
- Cruise Ships/Leisure Yachts
- Worldwide Embassies
- Military Medicine - Field Hospitals, Submarines and Surface Ships
- Oil and Gas Rigs
- Remote Mining Communities
- Emergency Rooms
- Small Laboratories
- Paediatric Applications
- Any POC Setting
- Remote Healthcare Centres
Parameters
Measured Analytes
pH, pCO2, pO2, TCO2, Na+, K+, Ca++, Cl-, HCT, Glu, Lac, Crea, BUN, Urea
Calculated Values
cHgb, cHCO3-, ctCO2, BE(ecf), BE(b), cSO2, GFRmdr*†, GFRmdr-a*†, GFRckd‡, GFRckd-a‡, GFRswz§, AGap, AGapK, BUN/Crea, Urea/Crea, A, A-a, a/A
Laboratories should establish and set their own normal range values.
*Values >60 will be reported as >60 mL/min/1.73 m2. †IDMS-traceable MDRD type. ‡CKD-EPI equation. §Bedside Schwartz equation.
Three Simple Steps to Using the epoc Blood Gas Analyser
Operating the epoc Blood Analyser is simple. A disposable epoc Test Card is inserted into the reader and an automatic calibration cycle is performed. A small sample of fresh whole blood (92μl) is then injected into the sample entry port on the test card. The reader then analyses the blood and approximately 35 seconds after sample injection, results are displayed on the epoc Host.
